Designed with clean lines and contemporary aesthetics.

RFID proximity solution, with maximizing ease and use, available in ON-LINE and OFF-LINE versions.

The ON-LINE solution allows the control by monitoring the presence cards using several readers located at building entrances and exits or in strategic locations. The attendance management is accomplished by software, responsible for the management and control of the readers. This application enables real-time view of the user status and system cards.

TECHNICAL DATA:

- RFID module, ISO 14443A (Mifare), with reading range up to 4 cm;
- Battery: external power supply 12V DC;
- Maximum number of users per door: 878;
- Maximum number of doors per system: 999.999;
- Maximum number of registered events in the unit: 439;
- Number of schedules: 24 (per lock);
- Number of access periods: configurable (minimum periods of 15 minutes);
- Common areas: 32;
- Users groups: unlimited;
- Relay capable to actuate electric strike DC 12V / 1A;
- Capable to actuate other devices such as electric drop bolt or magnetic lock;
- Alternative opening through external button (NO), with time control;
- Can receive information from door opening sensor;
- Protection class: IP54 (protection against dust and splashing water in all directions).

CHARACTERISTICS:

- Outdoor application;
- RFID identification technology – Proximity (without contact);
- Low power supply (12V DC);
- Free passage mode (doors maintain open allowing free movement);
- Record LOG events in non-volatile memory;
- Able to audit and configure through Programming Cards (OFF-LINE version) or
  through wireless network (ON-LINE version);
- Easy and intuitive access control software, for Windows®, with SQL database,
  multi-user support and available in several languages;
- Allows integration with several PMS systems for an easier guest card issuing and
  with POS systems, for client identification;
- Compatible with Smart (OFF-LINE) and Smart+ (ON-LINE) software.
